LTV-816S-TA1-B real image2202
Same model may have multiple batches, images only for reference.

LTV-816S-TA1-B

Part No LTV-816S-TA1-B
Manufacturer Lite-On Inc.
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATR 5KV TRANSISTOR 4SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Lite-On Inc.
Status Active
Number of Channels 1
Isolation Voltage 5000Vrms
Minimum DC Current Transfer Ratio 130% @ 5mA
Maximum DC Current Transfer Ratio 260% @ 5mA
Rise and Fall Time 4μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -50°C to 110°C
Win Source Part Number 303804-LTV-816S-TA1-B
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTV-816S-TA1-B CAD Model

Description

The LTV-816S-TA1-B is an optocoupler from Lite-On Inc. that provides high isolation voltage of 5000Vrms and a maximum output voltage of 80V.

  • Continuous Forward Current: 50mA
  • Forward Voltage: 1.2V
  • Vce Saturation: 200mV
  • Minimum DC Current Transfer Ratio: 130% @ 5mA
  • Maximum DC Current Transfer Ratio: 260% @ 5mA
  • Rise Time: 4μs
  • Fall Time: 3μs
  • Channel Output Current: 50mA
  • Temperature Range: -50°C to 110°C
  • Applications: Isolators
  • Supply and Demand Status: Balanced
