LTM9002CV-AA

Part No LTM9002CV-AA
Manufacturer Linear Technology
Catalog RF Misc ICs and Modules
Description IC RCVR IF/BASEBAND 14BIT 108LGA
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Linear Technology
Packaging Tray
Status Active
Purpose IF to Baseband Receiver
Frequency 0Hz to 300MHz
Secondary Attributes 14-Bit ADC
Case / Package 108-LGA (15x11.25)
Win Source Part Number 206814-LTM9002CV-AA
Ultra Librarian 3D Model Ultra Librarian LTM9002CV-AA CAD Model

Description

The LTM9002CV-AA is a part of Linear Technology's µModule® (micromodule) series, an innovative line of products that integrate all the critical components of an RF-to-digital receiver into a compact, single-package design. This product is designed to simplify the implementation of receiver subsystems in communication and instrumentation applications.

Key Features

  • Integrated System: The LTM9002CV-AA combines a high-performance 14-bit, 125Msps analog-to-digital converter (ADC) with a high-linearity RF downconverting mixer, creating a complete RF-to-digital conversion signal chain in a single module.
  • Frequency Range: The device is capable of operating over a broad frequency range, making it suitable for a wide array of applications, from base station receivers to test equipment.
  • High Integration: By integrating passive filtering, gain stages, and a phase-locked loop (PLL) with voltage-controlled oscillator (VCO), the LTM9002CV-AA reduces the need for complex external circuitry, saving space and simplifying the design process.
  • Performance: The ADC within the LTM9002CV-AA provides excellent dynamic performance, including a high signal-to-noise ratio (SNR) and spurious-free dynamic range (SFDR), critical for high-performance signal acquisition.

Applications

  • Wireless and Wired Broadband Communication
  • Remote Sensing and Satellite Terminals
  • Test and Measurement Equipment
  • Radar and Imaging Systems

Design Advantages

The LTM9002CV-AA is designed for ease of use, with minimal external components required. Its integrated features help reduce the complexity of RF system design and development time. The module provides excellent thermal performance due to its land grid array (LGA) package, ensuring reliable operation even in challenging environments.

With its robust feature set and high level of integration, the LTM9002CV-AA from Linear Technology is an excellent choice for designers looking to create efficient, high-performance RF receiver systems with reduced time-to-market.
