LTM4628EY#PBF

Part No LTM4628EY#PBF
Manufacturer Linear Technology
Catalog Power Supplies Board Mount DCDC Converters
Description DC/DC CNVRTR 2X0.6-5.5V 144BGA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Linear Technology
Series μModule
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 2
Input Voltage MIN 4.5V
Voltage Input MAX 26.5V
Voltage - Output 1 0.6 ~ 5.5 V
Voltage - Output 2 0.6 ~ 5.5 V
Current - Output (Maximum) 8A, 8A
Applications ITE (Commercial)
Features OCP, OVP, UVLO
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package 144-BBGA Module
Size 0.59" L x 0.59" W x 0.17" H (15.0mm x 15.0mm x 4.3mm)
Manufacturer Package 144-BGA (15x15)
Manufacturer Homepage www.linear.com
Win Source Part Number 715034-LTM4628EY#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTM4628E
Introduction Date November 08, 2010
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LTM4628EY#PBF CAD Model

Description

The LTM4628EY#PBF is a high-performance, dual 8A or single 16A output, step-down µModule (micromodule) regulator from Linear Technology that combines top-notch power management capabilities in a compact, encapsulated package. This product is designed to meet the needs of space-constrained applications requiring efficient power conversion with minimal external components.

Key Features:

  • Wide Input Voltage Range: The device operates from a 2.7V to 5.5V input supply, making it versatile for a variety of systems.
  • High Output Current: It provides dual 8A outputs that can be paralleled for up to 16A of output current, catering to high-power requirements.
  • Adjustable Output Voltage: The output voltage is adjustable from 0.6V to 5.5V, which allows for a wide range of uses in different circuit designs.
  • High Efficiency: With integrated switching controllers, power FETs, inductors and support components, the LTM4628EY#PBF is engineered to achieve high efficiency levels.
  • Compact Package: The product comes in a small (15mm x 15mm x 5.01mm) BGA package, which is ideal for space-constrained applications.
  • Thermal Performance: The µModule regulator is designed with advanced thermal management in mind, ensuring reliable performance even at full load.
  • Ease of Use: This device simplifies the design process by reducing the number of external components needed, which in turn reduces design risk and time to market.

Applications:

The LTM4628EY#PBF is suitable for a wide range of applications including:

  • Telecommunications and networking equipment
  • Servers and storage systems
  • Industrial equipment
  • Medical devices
  • High-density distributed power systems

Reliability and Quality:

Linear Technology ensures that the LTM4628EY#PBF µModule regulator meets stringent quality and reliability standards. The device is RoHS compliant and is designed to withstand harsh industrial environments, making it a reliable choice for critical applications.
