Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Hot Swap Controller
Number of Channels 2
Applications General Purpose
Features OVP, UVLO
Programmable Features Auto Retry, Circuit Breaker, Current Limit, Fault Timeout, Latched Fault
Supply Voltage - Operating 1 V to 13.5 V
Temperature Range - Operating -40°C to 85°C
Operating Supply Current 2.2mA
Mounting SMD (SMT)
Case / Package 16-SSOP
Feature Pins /FAULT, FILTER, FB1, FB2, ON1, ON2, PWRGD1, PWRGD2, TIMER
Win Source Part Number 138137-LTC4221IGN#TRPBF
Ultra Librarian 3D Model Ultra Librarian LTC4221IGN#TRPBF CAD Model

Description

Product Overview: LTC4221IGN#TRPBF

The LTC4221IGN#TRPBF is a sophisticated dual Hot Swap™ controller designed by Linear Technology to enable safe board insertion and removal from a live backplane. Crafted with precision, this integrated circuit is tailored to manage electronic circuit boards that connect to high-current power supplies, which is a common requirement in server farms and telecommunications equipment.

Key Features

  • Independent Control: The LTC4221IGN#TRPBF allows for the independent control of two supplies with external N-channel MOSFETs, ensuring precise operation and protection for each channel.
  • Adjustable Overcurrent Protection: Users can set the overcurrent threshold via an external resistor, providing flexibility and enhanced protection to meet the requirements of various applications.
  • Power Good Outputs: The device includes power good outputs which can be used for downstream load enabling and processor reset functions, thereby improving the reliability of the overall system.
  • Wide Operating Voltage Range: It operates over a wide range of supply voltages from 2.9V to 18V, accommodating various power levels needed for different electronic components.
  • Glitch Filtering: The LTC4221IGN#TRPBF provides glitch filtering on the ON pins to prevent false triggering due to transients, ensuring stable operation.

Applications

The controller is ideal for a multitude of applications that require power management and protection, including but not limited to:

  • RAID Systems
  • Network Servers
  • Telecommunication Systems
  • Industrial Systems

Package and Quality

The LTC4221IGN#TRPBF comes in a compact SSOP-16 (Shrink Small Outline Package) that ensures a minimal footprint on the PCB while providing adequate thermal performance. Linear Technology ensures high-quality standards, and the part is available in tape and reel packaging for easy assembly during the manufacturing process.

Conclusion

In conclusion, the LTC4221IGN#TRPBF from Linear Technology is a feature-rich dual Hot Swap™ controller that offers robust protection and precise control for high-availability systems. Its versatility and reliability make it an excellent choice for engineers looking to improve system safety and maintainability.
