Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Push-Pull, Totem Pole
Reset Active Low
Reset Timeout Adjustable/Selectable
Voltage - Threshold Adjustable/Selectable
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package TSOT-23-8
Win Source Part Number 020547-LTC2934ITS8-2#TRMPBF
Ultra Librarian 3D Model Ultra Librarian LTC2934ITS8-2#TRMPBF CAD Model

Description

LTC2934ITS8-2#TRMPBF - Ultra-Low Power Voltage Monitor

The LTC2934ITS8-2#TRMPBF is a sophisticated voltage monitoring device designed by Linear Technology to ensure the reliability and stability of electronic systems. This component is especially crucial for applications that require precise voltage control and ultra-low power consumption. The LTC2934ITS8-2#TRMPBF is tailored for battery-powered devices, portable equipment, and energy-sensitive applications where power efficiency is paramount.

With its tiny TSOT-23 package, this voltage monitor is an ideal solution for space-constrained designs. Despite its small size, the LTC2934ITS8-2#TRMPBF offers a wide range of features that make it a versatile component for various applications. It provides six selectable threshold voltages, ranging from 1.8V to 4.63V, which allows designers to choose the appropriate voltage level for their specific requirements.

One of the key features of this product is its ultra-low quiescent current, which is typically only 1.5µA. This characteristic is particularly important for extending battery life in portable devices. The LTC2934ITS8-2#TRMPBF also includes an adjustable reset timeout period, giving designers the flexibility to set the duration of the reset signal according to their system's needs.

The device offers a guaranteed threshold accuracy of ±1.5% over the entire operating temperature range of -40°C to 85°C. This ensures reliable operation even in extreme environmental conditions. Furthermore, the LTC2934ITS8-2#TRMPBF features a manual reset input, which provides an additional layer of control by allowing the user to trigger a system reset as needed.

For enhanced system protection, the LTC2934ITS8-2#TRMPBF includes an internally generated supply voltage supervisory circuit. This circuit actively monitors the supply voltage and provides an early warning signal if the voltage drops below the preset threshold, allowing the system to take corrective action before a malfunction occurs.

In conclusion, the LTC2934ITS8-2#TRMPBF from Linear Technology is a highly reliable and energy-efficient solution for voltage monitoring in critical applications. Its low power consumption, precision, and compact form factor make it an excellent choice for engineers looking to enhance system stability and extend the operational life of their battery-powered devices.
