Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Multi-Voltage Supervisor
Number of Voltages Monitored 4
Output Open Drain or Open Collector
Reset Active Low
Reset Timeout 5 ms Minimum
Voltage - Threshold 16 Selectable Threshold Combinations
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 10-MSOP
Win Source Part Number 134875-LTC2900-1IMS#TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC2900-1IMS#TRPBF CAD Model

Description

Product Overview: LTC2900-1IMS#TRPBF

The LTC2900-1IMS#TRPBF is a versatile quad voltage monitor from Linear Technology, designed to ensure the reliability and stability of electronic systems by monitoring multiple supply voltages. This precision monitoring solution is ideal for a wide range of applications, including system reset generation, power-on reset control, and power supply monitoring.

Key Features

  • Quad Input Voltage Monitoring: The device can monitor up to four different voltage levels simultaneously, making it a compact and efficient solution for systems with multiple supply voltages.
  • Adjustable Reset Thresholds: Users can set precise voltage thresholds for each monitor input, allowing for customized voltage supervision tailored to specific system requirements.
  • Low Quiescent Current: Its low power consumption ensures minimal impact on the overall power budget of the system, making it suitable for power-sensitive applications.
  • Wide Operating Voltage Range: The LTC2900-1IMS#TRPBF operates over a broad voltage range, accommodating various supply levels and providing versatile deployment options.
  • Multiple Output Options: The device offers both push-pull and open-drain output configurations, providing flexibility in interfacing with other system components.
  • Robust Packaging: Housed in a durable MSOP package, the LTC2900-1IMS#TRPBF is designed to withstand harsh environments and is suitable for industrial-grade applications.

Applications

The LTC2900-1IMS#TRPBF is an excellent choice for a variety of applications, including but not limited to:

  • Computer Systems
  • Network Servers
  • Telecommunications Equipment
  • Portable/Battery-Powered Devices
  • Industrial Control Systems

Quality and Reliability

Linear Technology is renowned for its commitment to quality, and the LTC2900-1IMS#TRPBF is no exception. It is designed to meet stringent industry standards, ensuring reliable operation and longevity in the field. With its advanced features and robust design, the LTC2900-1IMS#TRPBF is an essential component for systems requiring precise voltage monitoring and control.
