The LTC1563-2IGN#PBF is a highly integrated active RC lowpass filter produced by Linear Technology, now part of Analog Devices. This advanced component is designed to meet the stringent requirements of today's high-performance signal processing applications without the need for clock-driven switched capacitors.

Featuring a 4th-order filter with a fixed frequency response, the LTC1563-2IGN#PBF is specifically configured to provide a Butterworth characteristic, ensuring maximally flat passband without ripples. This makes it an ideal choice for applications requiring a clean and stable signal pass-through such as anti-aliasing for data acquisition systems, audio signal processing, and various communications equipment.

Key Features:

• Filter Order: 4th-order active RC lowpass filter
• Filter Response: Butterworth for maximally flat amplitude response
• Cutoff Frequency: Adjustable from 1kHz to 150kHz
• Supply Voltage: Single 5V supply
• Dynamic Range: 84dB at 1kHz
• Low Noise: 90μV RMS noise at 1kHz
• Package: 16-lead narrow SSOP package
• Part Number: LTC1563-2IGN#PBF

The LTC1563-2IGN#PBF is also noted for its ease of use, requiring no external components to set the filter's corner frequency. This corner frequency is easily set by a single external resistor, or it can be adjusted on-the-fly, which adds to the versatility of the design. The filter's dynamic range is maintained over the entire audio frequency range, making it exceptionally well-suited for high-fidelity audio applications.

In terms of design flexibility, the LTC1563-2IGN#PBF offers a simple, compact solution that reduces the complexity and component count of traditional filter designs. Its single-supply operation and integrated features make it an economical choice for a wide range of filtering applications, while the small footprint of the SSOP package allows for space-saving on the PCB.

Applications:

• Data Acquisition Systems
• Audio Processing Equipment
• Communications Systems
• Signal Conditioning
• Anti-Aliasing Filters
