Products specifications Report Issue?

Manufacturer Linear Technology/Analog Devices
Packaging Reel
Voltage - Clamping 27V Adj
Technology External Switch
Number of Circuits 1
Applications Automotive
Mounting Style SMD
Manufacturer Package 12-TSSOP
Supplier Device Package 12-MSOP
Voltage - Working 4 ~ 80V
Part Number Series LT4363
Manufacturer Pack Quantity 2,500
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 801869-LT4363IMS-1#TRPBF
Ultra Librarian 3D Model Ultra Librarian LT4363IMS-1#TRPBF CAD Model

Description

Product Overview: LT4363IMS-1#TRPBF

The LT4363IMS-1#TRPBF is a high-performance surge stopper integrated circuit (IC) designed and manufactured by Linear Technology. This advanced device is engineered to protect sensitive electronic systems from high voltage transients and overvoltage events, ensuring the longevity and reliability of the system it safeguards.

At the core of the LT4363IMS-1#TRPBF is its ability to control the gate of an external N-channel MOSFET to act as a variable resistor during transient overvoltage events. This feature allows the device to clamp the output voltage to a safe level without the need for large external components, making it an ideal choice for space-constrained applications.

The device operates over a wide input voltage range and can withstand surges up to 100V, making it suitable for a variety of industrial, automotive, and telecommunication applications. Its robust design includes an adjustable overvoltage lockout and an undervoltage lockout, which ensures that the system operates only when the supply voltage is within an acceptable range.

The LT4363IMS-1#TRPBF also features a fault timer, which provides an additional layer of protection by limiting the duration of overvoltage conditions, thereby preventing potential damage to the MOSFET. Moreover, the IC offers a status flag output that can be used to signal a fault condition to a microcontroller or other monitoring systems.

Packaged in a compact MSOP-10, this surge stopper is designed for easy implementation into existing designs. Its lead-free and RoHS-compliant construction ensures that it meets modern environmental standards, making it a responsible choice for eco-conscious manufacturers. The LT4363IMS-1#TRPBF's combination of features and compact size makes it an excellent choice for protecting power supplies, automotive electronics, and other critical systems against voltage transients.

In summary, the LT4363IMS-1#TRPBF from Linear Technology is a versatile and reliable solution for safeguarding sensitive electronics from voltage spikes and surges while maintaining a compact footprint and meeting environmental standards.
