Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Hot Swap Controller
Number of Channels 1
Applications General Purpose
Programmable Features Auto Retry, Current Limit, Fault Timeout, Latched Fault, OVP, Slew Rate, UVLO
Supply Voltage - Operating 10.8 V to 80 V
Temperature Range - Operating 0°C to 70°C
Operating Supply Current 1.8mA
Mounting SMD (SMT)
Case / Package 16-SSOP
Feature Pins FB, OPEN, OV, PWRGD, RETRY, TIMER, UV
Win Source Part Number 137478-LT4256-3CGN#TRPBF
Ultra Librarian 3D Model Ultra Librarian LT4256-3CGN#TRPBF CAD Model

Description

Product Overview: LT4256-3CGN#TRPBF

The LT4256-3CGN#TRPBF is a high-performance Hot Swap controller IC from Linear Technology, designed to allow a board to be safely inserted and removed from a live backplane. This particular component is housed in a 16-lead SSOP package and is available in tape and reel packaging, indicated by the suffix 'TRPBF', which is suitable for automated assembly processes.

Key Features

  • Wide Operating Voltage Range: The device can handle a wide range of supply voltages, making it versatile for various applications.
  • Adjustable Current Limit: Users can set the current limit threshold according to their specific requirements, ensuring protection against overcurrent conditions.
  • Fast Response to Short-Circuit: The LT4256-3CGN#TRPBF responds quickly to short-circuit conditions, providing rapid protection to the system.
  • Overvoltage Protection: The IC includes overvoltage protection, which ensures that the device and the system are safeguarded against voltage spikes.
  • Under Voltage Lockout: The under voltage lockout feature ensures that the device is operational only when the supply voltage is within the acceptable range.
  • Foldback Current Limiting: This feature helps to reduce the power dissipation during overcurrent conditions.
  • Gate Drive for External N-Channel MOSFET: The IC provides a gate drive voltage for an external N-Channel MOSFET, which acts as the main power control element.
  • Status Flag: An output flag is available to provide status feedback, which can be used for downstream signal processing or for triggering system alerts.

Applications

The LT4256-3CGN#TRPBF is ideal for a broad range of applications, including:

  • Hot Swap Systems
  • Network Servers and Routers
  • Industrial Systems
  • Telecommunications Equipment
  • Datacom and Telecom Switches

Quality and Reliability

Linear Technology is known for its commitment to high-quality products, and the LT4256-3CGN#TRPBF is no exception. It is manufactured to meet stringent industry standards, ensuring reliability and performance in even the most demanding environments.

In summary, the LT4256-3CGN#TRPBF is a sophisticated Hot Swap controller that offers a robust feature set for safe and efficient management of board insertion into live systems, making it a top choice for engineers and designers in the field of power management.
