Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Reference
Mfr Linear Technology
Package Bulk
Product Status Active
Reference Type Series
Output Type Fixed
Voltage - Output (Min/Fixed) 3.3V
Current - Output 100 mA
Tolerance ±0.15%
Temperature Coefficient 20ppm/°C
Noise - 0.1Hz to 10Hz 8ppmp-p
Noise - 10Hz to 10kHz 9.6ppmrms
Voltage - Input 3.8V ~ 20V
Current - Supply 70µA
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SO
Base Product Number LT1461
Standard Package 1 pcs
Moisture Sensitivity Level (MSL) Vendor Undefined
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 623042-LT1461DHS8-3.3
Ultra Librarian 3D Model Ultra Librarian LT1461DHS8-3.3 CAD Model

Description

Linear Technology's LT1461DHS8-3.3 Precision Voltage Reference

The LT1461DHS8-3.3 is a micropower, low dropout voltage reference from Linear Technology that offers high precision and stability. This component is part of Linear Technology's family of bandgap voltage references, designed to provide a stable and accurate reference voltage for high-performance analog circuits. The LT1461 series is characterized by its low noise and low thermal drift, making it an ideal choice for precision applications.

With an output voltage of 3.3 volts, the LT1461DHS8-3.3 provides a fixed reference that is essential for many analog-to-digital conversions, digital-to-analog conversions, and voltage monitoring applications. The device ensures a high degree of accuracy with an initial tolerance of just ±0.05% and temperature stability of ±10ppm/°C over the full temperature range of -40°C to 85°C. This precision is maintained over time with a long-term stability of less than 30ppm/1k hours, making it reliable for critical applications where consistent performance is necessary.

One of the key features of the LT1461DHS8-3.3 is its low dropout performance. With a low dropout voltage of typically 20mV, this component can operate with minimal headroom above the output voltage, allowing for efficient use in systems with tight supply tolerances. Additionally, the device has a low supply current of 60µA, which reduces power consumption and makes it suitable for battery-powered and portable applications.

The LT1461DHS8-3.3 comes in an 8-lead SOIC package, which is compact and suitable for space-constrained designs. Its robust design includes reverse battery protection, which safeguards the device against incorrect power supply connections. Furthermore, the output is able to drive up to 10mA, providing sufficient current for a wide range of loads.

Overall, the LT1461DHS8-3.3 is a high-quality component that offers engineers a precise and stable voltage reference. Its combination of low noise, high accuracy, and low power consumption makes it an excellent choice for precision data converters, portable instrumentation, and any application where a reliable reference voltage is critical.
