The LT1167ACS8#PBF is a high-performance instrumentation amplifier from Linear Technology, designed to offer precision and ease of use for a wide range of applications. This advanced amplifier is characterized by its single resistor gain programmability, which simplifies circuit design and reduces external component count.

Key Features

• Single Resistor Gain Set: The gain of the LT1167 is easily programmed with a single external resistor, which significantly simplifies the gain configuration process and allows for a wide range of gain settings.
• High Precision: With its low input offset voltage and low noise, the LT1167 provides high accuracy, making it ideal for precision data acquisition systems, medical instruments, and industrial process controls.
• Low Power Consumption: The device operates with a low supply current, making it suitable for battery-powered and portable applications without compromising performance.
• Wide Supply Range: It can operate from a single supply of 2.3V to 36V or dual supplies of ±1.15V to ±18V, offering flexibility in various power environments.
• Output Stage: The output stage offers high drive capability and is fully protected with an output short-circuit to ground.
• Common Mode Rejection Ratio (CMRR): The LT1167 features an excellent CMRR, which helps in rejecting noise and interference from common-mode signals.

Applications

The LT1167ACS8#PBF is versatile and can be used in numerous applications, such as:

• Test Equipment
• Medical Instrumentation
• Industrial Process Controls
• Strain Gauge Amplifiers
• Thermocouple Amplifiers
• Transducer Interfaces

Package and Quality

The LT1167ACS8#PBF comes in an 8-lead SOIC package, which is compact and suitable for space-constrained applications. The product adheres to Linear Technology's high-quality standards, ensuring reliability and performance consistency for critical applications.
