GAL20V8B-15LJ Lattice Semiconductor Corporation GAL20V8B-15LJ real image22322
Same model may have multiple batches, images only for reference.
GAL20V8B-15LJ Lattice Semiconductor Corporation GAL20V8B-15LJ real image22322
GAL20V8B-15LJ Lattice Semiconductor Corporation GAL20V8B-15LJ real image22322
Same model may have multiple batches, images only for reference.

GAL20V8B-15LJ

Part No GAL20V8B-15LJ
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 8MC 15NS 28PLCC / High Performance E2CMOS PLD Generic Array Logic™
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Lattice Semiconductor Corporation
Packaging Tube
Part Status Obsolete (End Of Life)
Programmable Type EE PLD
Delay Time tpd(1) Max 15ns
Voltage Supply - Internal 4.75V ~ 5.25V
Number of Macrocells 8
Temperature Range - Operating 0°C ~ 75°C
Mounting Style SMD
Manufacturer Package 28-LCC (J-Lead)
Supplier Device Package 28-PLCC (11.51x11.51)
Part Number Series GAL20V8
Manufacturer Pack Quantity 370
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 803549-GAL20V8B-15LJ
Ultra Librarian 3D Model Ultra Librarian GAL20V8B-15LJ CAD Model

Description

The Lattice Semiconductor Corporation GAL20V8B-15LJ is a programmable EE PLD with a delay time tpd(1) max of 15ns.

  • Delay Time tpd(1) max: 15ns
  • Voltage Supply: 4.75V to 5.25V
  • Macrocells: 8
  • Package: 28-PLCC (11.51x11.51)
  • Operating Temperature: 0°C to 75°C
  • Part Status: Obsolete (End Of Life)
  • Popularity: Medium
  • Manufacturer Package: 370 pieces
  • MSL Level: 3 (168 Hours)
