CM2824B103R-10 Laird-Signal Integrity Products – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

CM2824B103R-10

Part No CM2824B103R-10
Manufacturer Laird-Signal Integrity Products
Catalog Common Mode Chokes
Description CMC 200MA 2LN 400 OHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power, Signal Line
Number of Lines 2
Impedance @ Frequency 400 Ohms @ 100 MHz
Current Rating (Max) 200mA
DC Resistance (DCR) (Max) 1.3Ohm
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 100°C
Mounting Type Surface Mount
Size / Dimension 0.354" L x 0.217" W (9.00mm x 5.50mm)
Height (Max) 0.193" (4.90mm)
Case / Package Horizontal, 4 Flat Lead
Package Tape & Reel
Supply and Demand Status Normal
Win Source Part Number 1527530-CM2824B103R-10
Ultra Librarian 3D Model Ultra Librarian CM2824B103R-10 CAD Model

Description

N
