SNT-D10T Real Image
Same model may have multiple batches, images only for reference.

SNT-D10T

Part No SNT-D10T
Manufacturer Kemet
Catalog Common Mode Chokes
Datasheet
SNT-D10T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr KEMET
Series SNT
Filter Type Signal Line
Number of Lines 2
Inductance @ Frequency 2.5 µH @ 100 kHz
Current Rating (Max) 3A
DC Resistance (DCR) (Max) 25Ohm
Temperature Range - Operating -20°C ~ 60°C
Mounting Type Through Hole
Dimension 0.374" L x 0.236" W (9.50mm x 6.00mm)
Height (Max) 0.500" (12.70mm)
Package / Case Vertical, 2 PC Pin
Base Product Number SNT-D
Other Names 399-SNT-D10TTR,UDLSNT0D10T000
Standard Package 1,000
MSL Level Not Applicable
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 1276806-SNT-D10T
Ultra Librarian 3D Model Ultra Librarian SNT-D10T CAD Model

Description

The KEMET SNT-D10T Common Mode Choke is a signal line filter with a 3A current rating (max) and a 2.5 µH inductance @ 100 kHz frequency.

  • Filter Type: Signal line
  • Current Rating (Max): 3A
  • Inductance @ Frequency: 2.5 µH @ 100 kHz
  • DC Resistance (DCR): 25Ohm
  • Height: 0.500" (12.70mm)
  • Package/Case: Vertical, 2 PC pin
  • Mounting Type: Through-Hole
It is designed to be used in applications such as noise suppression in power circuits, signal lines, and data lines.
