WP7-P024VA1-R6000 JAE Electronics
Same model may have multiple batches, images only for reference.

WP7-P024VA1-R6000

Part No WP7-P024VA1-R6000
Manufacturer JAE Electronics
Catalog Rectangular Connectors
Description CONN PLUG 24POS SMD GOLD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer JAE Electronics
Packaging Reel
Part Status Obsolete (End Of Life)
Connector Type Plug, Outer Shroud Contacts
Number of Positions 24
Pitch 0.016" (0.40mm)
Number of Rows 2
Mounting Style SMD
Features Solder Retention
Contact Finish Gold
Contact Finish Thickness 3.94μin (0.10μm)
Mated Stacking Heights 0.7mm
Height Above Board 0.020" (0.50mm)
Manufacturer Pack Quantity 6,000
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Balance
Win Source Part Number 802463-WP7-P024VA1-R6000
Ultra Librarian 3D Model Ultra Librarian WP7-P024VA1-R6000 CAD Model

Description

The WP7-P024VA1-R6000 is a 24 position connector plug manufactured by JAE Electronics.

  • Series: WP7
  • Contact Surface: Gold
  • Pitch: 0.016" (0.40mm)
  • Mounting: Surface Mount
  • Contacts: Outer Shroud
  • Packaging: Reel
  • Manufacturer Pack Quantity: 6,000
