Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Gate Drivers
Mfr IXYS
Package Tape & Reel
Product Status Active
Programmable Not Verified
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type IGBT, N-Channel, P-Channel MOSFET
Voltage - Supply 4.5V ~ 35V
Logic Voltage - VIL, VIH 0.8V, 3V
Current - Peak Output (Source, Sink) 9A, 9A
Input Type Non-Inverting
Rise / Fall Time (Typ) 22ns, 15ns
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width) Exposed Pad
Supplier Device Package 8-SOIC-EP
Base Product Number IXDN609
Standard Package 2,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
California Prop 65 Warning Information
Win Source Part Number 876059-IXDN609SITR
Ultra Librarian 3D Model Ultra Librarian IXDN609SITR CAD Model

Description

The IXDN609SITR is a gate driver IC in an 8-SOIC (0.154", 3.90mm Width) exposed pad package.

  • Designed For: Power management applications
  • Channel: Single channel
  • Driven Configuration: Low-side
  • Input Type: Non-inverting
  • Compatible With: IGBTs, N-Channel MOSFETs, and P-Channel MOSFETs
  • Logic Voltage Range: 0.8V to 3V
  • Peak Output Current (Source): 9A
  • Peak Output Current (Sink): 9A
  • Rise/Fall Time: 22ns and 15ns
  • Operating Temperature: -55°C to 150°C
  • California Prop 65: Not affected
  • Market Status: Active
