DSEI12-06A Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 14A
Voltage - Forward (Vf) (Max) @ If 1.7V @ 16A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 50ns
Current - Reverse Leakage @ Vr 50μA @ 600V
Mounting Through Hole
Case / Package TO-220AC
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 050932-DSEI12-06A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DSEI12-06A CAD Model

Description

DSEI12-06A - Fast Recovery Diode

The DSEI12-06A is engineered for applications demanding fast recovery times and efficient power handling. It is particularly effective in various inverters and converters, ensuring dependable performance and minimal power loss.

Applications/Projects:

  • Inverter systems
  • DC-DC converters
  • UPS systems
  • Frequency converters

Features and Benefits:

  • Fast recovery times reduce switching losses.
  • Low power dissipation for enhanced system efficiency.
  • High reliability with a compact design.
  • Optimized for high-frequency operation.

Additional Details: This diode is packaged in an adaptable TO-220AC design, promoting ease of use in diverse electronic setups.
