Products specifications

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr IXYS
Series HiPerFRED™
Package Tube
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology Standard
Voltage - DC Reverse (Vr) (Max) 300 V
Current - Average Rectified (Io) (per Diode) 10A
Voltage - Forward (Vf) (Max) @ If 1.27 V @ 10 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 35 ns
Current - Reverse Leakage @ Vr 1 µA @ 300 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220-3
Base Product Number DPG20C300
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 585782-DPG20C300PB
Ultra Librarian 3D Model Ultra Librarian DPG20C300PB CAD Model

Description

The HiPerFRED™ series diode array with the part number 585782-DPG20C300PB is a fast recovery diode array designed for rectification applications.

  • Maximum DC Reverse Voltage (Vr): 300V
  • Maximum Forward Voltage (Vf): 1.27V @ 10A
  • Reverse Recovery Time (trr): 35ns
  • Average Rectified Current (Io) per Diode: 10A
  • Diode Configuration: 1 pair common cathode
  • Mounting Type: Through-Hole
  • Package: TO-220-3
  • Package Quantity: 50 pcs (Tube)
  • Operating Temperature Range: -55°C to 175°C
  • Manufacturer: IXYS
