Products specifications

Reference Date Code 14/15+
Reference case BGA
Manufacturer ITE
Win Source Part Number 710578-IT8518VG/HX
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IT8518VG/HX CAD Model

Description

The IT8518VG/HX is a highly integrated embedded controller manufactured by ITE. This controller typically serves as a Super I/O and Embedded Controller, handling various low-level functions within a computer system. It manages tasks such as keyboard and mouse input, fan control, and power management, contributing to the overall efficiency and functionality of the device.

Applications:

  • Super I/O functions in laptop computers.
  • Embedded controller for fan control in desktop PCs.
  • Power management in notebooks.
  • Keyboard and mouse interface.
  • Temperature monitoring in embedded systems.

Features:

  • Keyboard and mouse controller.
  • Fan speed control.
  • Power management features.
  • Temperature sensor interface.
  • Serial communication interfaces (UART, SPI, I2C).

Benefits:

  • Reduced component count.
  • Improved system efficiency.
  • Enhanced power management capabilities.
  • Simplified system design.
  • Increased system reliability.

Additional Details:

The IT8518VG/HX integrates multiple functions into a single chip, reducing the number of discrete components required on the motherboard. This integration helps to save space and reduce overall system cost. The embedded controller provides precise control over fan speeds, allowing for efficient cooling and reduced noise. Its power management features help to optimize energy consumption, extending battery life in portable devices and reducing power consumption in desktop systems.

The controller also includes interfaces for connecting temperature sensors, enabling the system to monitor and respond to changes in temperature. Serial communication interfaces such as UART, SPI, and I2C allow the controller to communicate with other devices in the system. The IT8518VG/HX is designed to meet the demanding requirements of modern computer systems, providing a comprehensive solution for Super I/O and embedded control functions.
