Categories Integrated Circuits
Manufacturer Intersil
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 3/3
Duplex Full
Receiver Hysteresis 500mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 24-TSSOP
Win Source Part Number 1048756-ISL83387EIVZ
Popularity Medium
Supply and Demand Status Balance
Quantity per package 62
Ultra Librarian 3D Model Ultra Librarian ISL83387EIVZ CAD Model

Description

The ISL83387EIVZ is a high-speed, low-power, single-channel RS-485 transceiver manufactured by Intersil (now Renesas). It is designed for robust communication in harsh industrial environments, offering excellent noise immunity and ESD protection.

Applications:

  • Industrial Networks
  • Building Automation
  • Motor Control
  • Security Systems
  • Point-of-Sale (POS) Systems

Features:

  • Data Rate: Up to 20Mbps
  • Supply Voltage: 3V to 5.5V
  • ESD Protection: ±15kV HBM (Human Body Model)
  • Low Power Consumption: 300μA typical supply current
  • Half-Duplex Operation
  • Driver Output Short-Circuit Protection
  • Receiver Input Hysteresis for Noise Rejection
  • Thermal Shutdown Protection
  • Package: SOIC-8

Benefits:

  • Robust Communication: Provides reliable communication in noisy environments due to its high ESD protection and noise immunity.
  • High Data Rate: Supports data rates up to 20Mbps, enabling fast data transfer.
  • Low Power Consumption: Minimizes power consumption, making it suitable for battery-powered applications.
  • Wide Supply Voltage Range: Operates from 3V to 5.5V, providing flexibility in system design.
  • Overcurrent Protection: Protects the driver from damage due to short circuits.

Additional Details:

The ISL83387EIVZ is a single transceiver that meets the RS-485 and RS-422 standards. It integrates a driver and a receiver in a single chip, simplifying system design and reducing board space. The device features a robust design with high ESD protection and excellent noise immunity, ensuring reliable communication in harsh industrial environments. The half-duplex operation allows for bidirectional communication over a single twisted pair cable. The device's low power consumption makes it suitable for battery-powered and energy-efficient applications. It includes thermal shutdown protection to prevent damage from overheating.

The high data rate capability allows for fast data transfer in applications such as motor control, industrial automation, and building automation. The device is commonly used in networks where reliable communication and high noise immunity are critical requirements.
