ISL83202IBZT Real Image ISL83202IBZT real image470
Same model may have multiple batches, images only for reference.
ISL83202IBZT Real Image ISL83202IBZT real image470
ISL83202IBZT Real Image ISL83202IBZT real image470
Same model may have multiple batches, images only for reference.

ISL83202IBZT

Part No ISL83202IBZT
Manufacturer Intersil
Catalog PMIC - Gate Drivers
Description IC FET DRIVER H-BRIDGE 1A 16SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 4
Gate Type N-Channel MOSFET
Supply Voltage - Operating 8.5 V to 15 V
Logic Voltage - VIL, VIH 1V, 2.5V
Current - Peak Output (Source, Sink) 1A, 1A
Input Type Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap) 70V
Rise and Fall Time 9ns, 9ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 040883-ISL83202IBZT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISL83202IBZT CAD Model

Description

The Intersil ISL83202IBZT is a half-bridge independent channel type driver with 4 number of drivers.

  • Input Type: Inverting and non-inverting
  • Gate Type: N-Channel MOSFET
  • Logic Voltage - VIL, VIH: 1V, 2.5V
  • Peak Output Current: 1A, 1A
  • High Side Voltage: 70V
  • Supply Voltage Range: 8.5V to 15V
  • Rise and Fall Time: 9ns, 9ns
  • Package: 16-SOIC package
  • Supply and Demand Status: Balanced
