Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Intersil
Packaging Tube
Type Transceiver
Protocol RS232, RS422, RS485
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 35mV
Data Rate 20Mbps
Operating Supply Voltage 4.5 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 28-SSOP (0.209", 5.30mm Width)
Manufacturer Package 28-SSOP
Win Source Part Number 777428-ISL81334IAZ
Popularity Medium
Supply and Demand Status Limited
Family Name ISL81334
Introduction Date March 27, 2003
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian ISL81334IAZ CAD Model

Description

The Intersil ISL81334IAZ is a transceiver used for RS232, RS422, and RS485 protocols from Intersil.

  • Drivers: 2
  • Receivers: 2
  • Duplex: Full
  • Package: 28-SSOP
  • Width: 0.209 inches
  • Mounting: SMD
  • Data Rate: 20Mbps
  • Receiver Hysteresis: 35mV
  • Family: ISL81334
  • Status: Active, Medium Popularity
  • Operating Supply Voltage: 4.5 V to 5.5 V
  • Operating Temperature: -40°C to 85°C
