Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Intersil
Main Purpose DC/DC, Step Down with LDO
Outputs and Type 5, Non-Isolated
Voltage - Output 3.3V, 3.3V, 5V, 5V, 14V
Regulator Topology Buck
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part ISL6236
Win Source Part Number 777363-ISL6236EVAL1
Popularity Medium
Supply and Demand Status Limited
Family Name ISL6236
Introduction Date October 05, 2006
ECCN EAR99
Country of Origin United States of America
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian ISL6236EVAL1 CAD Model

Description

The Intersil ISL6236EVAL1 is a fully populated development board that is designed for use in DC/DC step-down applications with LDO.

  • Outputs: Five non-isolated
  • Based On: ISL6236 IC/part
  • Regulator Topology: Buck
  • Voltage Outputs: 3.3V, 3.3V, 5V, 5V, 14V
  • Applications: Telecommunications, wireless communication systems
