HIP4081AIBZ Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 4
Gate Type N-Channel MOSFET
Supply Voltage - Operating 9.5 V to 15 V
Logic Voltage - VIL, VIH 1V, 2.5V
Current - Peak Output (Source, Sink) 2.6A, 2.4A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 95V
Rise and Fall Time 10ns, 10ns
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 20-SOIC
Win Source Part Number 087522-HIP4081AIBZ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Motor Drive & Control, Power Management, Automotive, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian HIP4081AIBZ CAD Model

Description

The Intersil HIP4081AIBZ is a high-popularity integrated circuit that is ideal for motor drive and control, power management, automotive, computers, and computer peripherals.

  • Input Type: Non-inverting
  • Driven Configuration: Half-bridge
  • Channels: Four independent
  • Gate Type: N-channel MOSFET
  • Logic Voltage: VIL=1V, VIH=2.5V
  • Peak Output Current: 2.6A (source), 2.4A (sink)
  • High-Side Voltage: 95V (max)
  • Temperature Range: -40°C to 125°C (TJ)
  • Package: 20-SOIC
  • Supply Voltage: 9.5 V to 15 V
  • Rise and Fall Time: 10ns
  • Supply and Demand Status: Limited
