Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Number of I/O 24
Interrupt Output No
Output Type Open Drain
Current - Output Source/Sink 2.5mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 44-PLCC (16.58x16.58)
Win Source Part Number 000281-CS82C55AZ96
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name CS82C55AZ96
Introduction Date May 22, 1998
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian CS82C55AZ96 CAD Model

Description

Product Overview

The CS82C55AZ96 offers seamless interfacing solutions between peripheral devices and microprocessors, highlighting its adaptability and efficient design.

Features and Benefits

  • High-speed data transfer rates.
  • Low power consumption due to CMOS technology.
  • Flexible and programmable input/output ports.
  • Interchangeable with a wide range of microprocessor types.

Applications

  • Home automation systems.
  • Embedded computing systems.
  • Medical instrumentation.
  • Robotics and control systems.

Additional Details

The flexibility and performance of the CS82C55AZ96 make it ideal for complex interfacing scenarios, facilitating effective communication between the CPU and peripheral devices.
