5CSEBA6U19C7N Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - System On Chip (SoC)
Mfr Intel
Series Cyclone® V SE
Package Tray
Architecture MCU, FPGA
Core Processor Dual ARM® Cortex®-A9 MPCore™ with CoreSight™
RAM Size 64KB
Peripherals DMA, POR, WDT
Connectivity CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG
Speed 800MHz
Primary Attributes FPGA - 110K Logic Elements
Temperature Range - Operating 0°C ~ 85°C (TJ)
Package / Case 484-FBGA
Supplier Device Package 484-UBGA (19x19)
Number of I/O MCU - 151, FPGA - 66
Base Product Number 5CSEBA6
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A001A7B
HTSUS 8542.39.0001
Other Names 966124
Standard Package 84
Win Source Part Number 1316369-5CSEBA6U19C7N
Ultra Librarian 3D Model Ultra Librarian 5CSEBA6U19C7N CAD Model

Description

The 5CSEBA6U19C7N is an embedded system on chip (SoC) with a Cyclone® V SE series from Intel.

  • Core Processor: Dual ARM® Cortex®-A9 MPCore™ with CoreSight™
  • Speed: 800MHz
  • Package: 484-FBGA
  • Packaging: Tray
  • Connectivity: CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART and USB OTG
  • Peripherals: DMA, POR, and WDT
  • Number of I/O (MCU): 151
  • Number of I/O (FPGA): 66
  • RAM Size: 64KB
  • Architecture: MCU, FPGA
  • Primary Attributes: FPGA - 110K Logic Elements
  • Operating Temperature Range: 0°C to 85°C (TJ)
