10M08SAE144C8G Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - FPGAs (Field Programmable Gate Array)
Mfr Intel
Series MAX® 10
Package Tray
Product Status Active
Programmable Not Verified
Number of LABs/CLBs 500
Number of Logic Elements/Cells 8000
Total RAM Bits 387072
Number of I/O 101
Voltage - Supply 2.85V ~ 3.465V
Mounting Type Surface Mount
Temperature Range - Operating 0°C ~ 85°C (TJ)
Package / Case 144-LQFP Exposed Pad
Supplier Device Package 144-EQFP (20x20)
Standard Package 60 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991D
HTSUS 8542.39.0001
Win Source Part Number 853716-10M08SAE144C8G
Ultra Librarian 3D Model Ultra Librarian 10M08SAE144C8G CAD Model

Description

The Intel 853716-10M08SAE144C8G is an FPGA from the MAX® 10 series.

  • Application: Embedded applications
  • I/O Pins: 101
  • LABs/CLBs: 500
  • Logic Elements/Cells: 8000
  • RAM Bits: 387072
  • Voltage Supply Range: 2.85V to 3.465V
  • Temperature Range: 0°C to 85°C
  • Package: 144-LQFP Exposed Pad
  • Installation: Surface mount
