Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - FPGAs (Field Programmable Gate Array)
Mfr Intel
Series Cyclone® 10 LP
Package Tray
Number of LABs/CLBs 392
Number of Logic Elements/Cells 6272
Total RAM Bits 276480
Number of I/O 88
Voltage - Supply 1.2V
Mounting SMD (SMT)
Temperature Range - Operating 0°C ~ 85°C (TJ)
Package / Case 144-LQFP Exposed Pad
Supplier Device Package 144-EQFP (20x20)
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 965562
Standard Package 60
Win Source Part Number 982989-10CL006YE144C8G
Ultra Librarian 3D Model Ultra Librarian 10CL006YE144C8G CAD Model

Description

The Win Source Part Number 982989-10CL006YE144C8G is a Cyclone® 10 LP Field Programmable Gate Array (FPGA) from Intel.

  • I/O Channels: 88
  • LABs/CLBs: 392
  • Logic Elements/Cells: 6272
  • Total RAM: 276480 bits
  • Voltage Supply: 1.2V
  • Package: 144-LQFP Exposed Pad
  • Mounted using: surface mount technology
  • ECCN: EAR99
  • HTSUS: 8542.39.0001
  • MSL Level: 3
  • REACH: unaffected
