Same model may have multiple batches, images only for reference.
TLE4955CXAMA1 Real Image
Same model may have multiple batches, images only for reference.

TLE4955CXAMA1

Part No TLE4955CXAMA1
Manufacturer Infineon Technologies
Catalog Magnetic Sensors - Switches (Solid State)
Description MAG SWITCH SPEC PURP SSO-2-53 / Digital Switch Special Purpose Current Source Hall Effect PG-SSO-2-53
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Magnetic Sensors - Switches (Solid State)
Mfr Infineon Technologies
Series TLE
Package Cut Tape (CT),Tape & Box (TB)
Function Special Purpose
Technology Hall Effect
Polarization North Pole, South Pole
Sensing Range -30mT Trip, 30mT Release
Test Condition 25°C
Voltage - Supply 4V ~ 20V
Current - Supply (Max) 16mA
Output Type Current Source
Temperature Range - Operating -40°C ~ 110°C (TJ)
Mounting Type Through Hole
Supplier Device Package PG-SSO-2-53
Package / Case 2-SIP, SSO-2-53
Base Product Number TLE4955
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 448-TLE4955CXAMA1TB,448-TLE4955CXAMA1CT,TLE4955CXAMA1-ND,SP001952972
Standard Package 1,500
Win Source Part Number 1099713-TLE4955CXAMA1
Ultra Librarian 3D Model Ultra Librarian TLE4955CXAMA1 CAD Model

Description

The Infineon Technologies TLE4955CXAMA1 magnetic sensor/switch is an ideal component for various applications that require magnetic sensing.

  • Win Source Part Number: 1099713-TLE4955CXAMA1
  • Series: TLE
  • Technology: Hall Effect
  • Output Type: Current Source
  • Sensing Range: -30mT trip, 30mT release
  • Voltage - Supply: 4V ~ 20V
  • Mounting Type: Through Hole
  • Package / Case: 2-SIP, SSO-2-53
  • RoHS Status: Compliant
  • REACH Status: Unaffected
