IRS2004STRPBF

Name: IRS2004STRPBF
Brand: Infineon Technologies
SKU: 462907
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRS2004STRPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC DRIVER HALF-BRIDGE 8-SOIC
Datasheet	IRS2004STRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Synchronous
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	10 V to 20 V
Logic Voltage - VIL, VIH	0.8V, 2.5V
Current - Peak Output (Source, Sink)	290mA, 600mA
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	200V
Rise and Fall Time	70ns, 35ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	1047726-IRS2004STRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRS2004
Introduction Date	June 12, 2006
ECCN	EAR99
Country of Origin	China, Thailand
Halogen Free	Compliant
Estimated EOL Date	2019
Ultra Librarian 3D Model	Ultra Librarian IRS2004STRPBF CAD Model

Description

The IRS2004STRPBF is a half-bridge gate driver IC manufactured by Infineon Technologies.

Configuration: Half-Bridge
Supply Voltage Range: 10V to 20V
Peak Output Current (Source): 290mA
Peak Output Current (Sink): 600mA
Package: 8-SOIC
Rise Time: 70ns
Fall Time: 35ns
