IRG4PC40UDPBF Real Image IRG4PC40UDPBF Real Image
Same model may have multiple batches, images only for reference.
IRG4PC40UDPBF Real Image IRG4PC40UDPBF Real Image
IRG4PC40UDPBF Real Image IRG4PC40UDPBF Real Image
Same model may have multiple batches, images only for reference.

IRG4PC40UDPBF

Part No IRG4PC40UDPBF
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 600V 40A 160W TO247AC
Datasheet
IRG4PC40UDPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Bulk
Status Active
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 40A
Pulsed Collector Current 160A
Collector-emitter saturation voltage(Max) 2.1V @ 15V, 20A
Maximum Power Dissipation 160W
Total Switching Energy(Ets) 710μJ (on), 350μJ (off)
Input Type Standard
Gate Charge 100nC
Turn-on and Turn-off delay time 54ns/110ns
Testing Conditions 480V, 20A, 10 Ohm, 15V
Reverse Recovery Time (trr) 42ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 016634-IRG4PC40UDPBF
Family Name IRG4PC40UD
Introduction Date October 28, 2010
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRG4PC40UDPBF CAD Model

Description

The Infineon Technologies IRG4PC40UDPBF is a TO-247AC packaged IGBT type device.

  • Maximum Collector Current: 40A
  • VCEO Maximum Collector-Emitter Breakdown Voltage: 600V
  • Maximum Power Dissipation: 160W
  • Pulsed Collector Current: 160A
  • Collector-Emitter Saturation Voltage (Max): 2.1V @ 15V, 20A
  • Total Switching Energy (Ets): 710μJ (on), 350μJ (off)
  • Turn-On and Turn-Off Delay Time: 54ns/110ns
  • Mounting Type: Through-Hole
  • Operating Temperature: -55°C to 150°C (TJ)
