IRG4BC20SDPBF

Name: IRG4BC20SDPBF
Brand: Infineon Technologies
SKU: 161148
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	IRG4BC20SDPBF
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	IGBT 600V 19A 60W TO220AB
Datasheet	IRG4BC20SDPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Obsolete(EOL)
VCEO Maximum Collector-Emitter Breakdown Voltage	600V
Maximum Current Collector	19A
Pulsed Collector Current	38A
Collector-emitter saturation voltage(Max)	1.6V @ 15V, 10A
Maximum Power Dissipation	60W
Total Switching Energy(Ets)	320μJ (on), 2.58mJ (off)
Input Type	Standard
Gate Charge	27nC
Turn-on and Turn-off delay time	62ns/690ns
Testing Conditions	480V, 10A, 50 Ohm, 15V
Reverse Recovery Time (trr)	37ns
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	TO-220AB
Win Source Part Number	205422-IRG4BC20SDPBF
Family Name	IRG4BC20SD
Introduction Date	January 13, 2004
ECCN	EAR99
Country of Origin	Mexico
Halogen Free	Not Compliant
Estimated EOL Date	Obsolete
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRG4BC20SDPBF CAD Model

Description

The Infineon Technologies 205422-IRG4BC20SDPBF is a through hole mounted IGBT transistor, which is a member of the IRG4BC20SD family of products.

Mounting Type: Through Hole
Product Status: Obsolete
Maximum Collector-Emitter Breakdown Voltage: 600V
Maximum Current Collector: 19A
Reverse Recovery Time: 37ns
Gate Charge: 27nC
Total Switching Energy (on): 320μJ
Total Switching Energy (off): 2.58mJ
Package: TO-220AB
Temperature Range: -55°C to 150°C (TJ)
Maximum Power Dissipation: 60W
Pulsed Collector Current: 38A
Collector-Emitter Saturation Voltage (Max): 1.6V @ 15V, 10A
Turn-On Delay Time: 62ns
Turn-Off Delay Time: 690ns
Popularity: High
