Same model may have multiple batches, images only for reference.

IRF7425TR

Name: IRF7425TR
Brand: Infineon Technologies
SKU: 604588
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRF7425TR
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	Trans MOSFET P-CH Si 20V 15A 8-Pin SOIC T/R / Ultra Low On-Resistance \| MOSFET P-CH 20V 15A 8-SOIC
Datasheet	IRF7425TR Datasheet
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tape and Reel
Status	Obsolete
Transistor Polarity	P-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	20V
Id - Continuous Drain Current	15A
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 4.5V
Rds On (Maximum) at Id, Vgs	8.2mOhm at 15A, 4.5V
Gate Source Voltage(th) (Maximum) at Id	1.2V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	130nC at 4.5V
Gate Source Voltage (Maximum)	±12V
Input Capacitance (Ciss) (Maximum) at Vds	7980pF at 15V
Power Dissipation (Maximum)	2.5W
Temperature Range - Operating	-55°C ~ 150°C
Mounting Style	SMD
Supplier Device Package	8-SO
Manufacturer Package	8-SOIC
Manufacturer Pack Quantity	4,000
MSL Level	1 (Unlimited)
Win Source Part Number	1187276-IRF7425TR
Manufacturer Homepage	www.irf.com
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRF7425
Introduction Date	November 29, 2000
ECCN	EAR99
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian IRF7425TR CAD Model

Description

Infineon Technologies IRF7425TR is a P-channel MOSFET transistor with a drain-source breakdown voltage of 20V.

GPTDescription: It features an 8-SOIC mounting style and a maximum power dissipation of 2.5W.
GPTDescription: The transistor has a maximum continuous drain current of 15A and a maximum on-resistance of 8.2mOhm @ 15A and 4.5V.
GPTDescription: The gate charge is 130nC @ 4.5V, and the gate-source voltage is ±12V.
GPTDescription: The IRF7425TR is commonly used in discrete semiconductor products and has a temperature range of -55°C to 150°C.
