IR2110S

Name: IR2110S
Brand: Infineon Technologies
SKU: 603868
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IR2110S
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	HIGH AND LOW SIDE DRIVER \| IC DRIVER HIGH/LOW SIDE 16-SOIC
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Tube
Status	Obsolete
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage (V)	3.3V ~ 20V
Logic Voltage - VIL, VIH	6V, 9.5V
Current - Peak Output (Source, Sink)	2A, 2A
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	500V
Rise / Fall Time	25ns, 17ns
Temperature Range - Operating	-40°C ~ 150°C
Mounting Style	SMD
Manufacturer Package	16-SOIC
Supplier Device Package	16-SOIC
Family Part Number	IR2110S
Manufacturer Pack Quantity	45
MSL Level	3 (168 Hours)
Win Source Part Number	1186556-IR2110S
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IR2110S CAD Model

Description

The Infineon Technologies IR2110S is an independent channel type half-bridge driven configuration gate driver IC.

Channel Type: Independent
Configuration: Half-Bridge Driven
Drivers: Two
Gate Types: IGBT and N-channel MOSFET
Input Type: Non-Inverting
Logic Voltage VIL: 6V
Logic Voltage VIH: 9.5V
Peak Output Current (Source): 2A
Peak Output Current (Sink): 2A
Bootstrap High Side Voltage (Max): 500V
Package: 16-SOIC
Operating Temperature Range: -40°C to 150°C
