IKW40N60DTPXKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IKW40N60DTPXKSA1

Part No IKW40N60DTPXKSA1
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT TRENCH/FS 600V 67A TO247-3 / IGBT Trench Field Stop 600 V 67 A 246 W Through Hole PG-TO247-3
Datasheet
IKW40N60DTPXKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - IGBTs - Single
Mfr Infineon Technologies
Series TrenchStop™
Package Tube
Product Status Not For New Designs
IGBT Type Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) 600 V
Current - Collector (Ic) (Max) 67 A
Current - Collector Pulsed (Icm) 120 A
Vce(on) (Max) @ Vge, Ic 1.8V @ 15V, 40A
Power - Max 246 W
Switching Energy 1.06mJ (on), 610µJ (off)
Input Type Standard
Gate Charge 177 nC
Td (on/off) @ 25°C 18ns/222ns
Test Condition 400V, 40A, 10.1Ohm, 15V
Reverse Recovery Time (trr) 87 ns
Temperature Range - Operating -40°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package PG-TO247-3
Base Product Number IKW40N60
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names INFINFIKW40N60DTPXKSA1,SP001379680,2156-IKW40N60DTPXKSA1
Standard Package 30
Win Source Part Number 1022674-IKW40N60DTPXKSA1
Ultra Librarian 3D Model Ultra Librarian IKW40N60DTPXKSA1 CAD Model

Description

The Infineon Technologies IKW40N60DTPXKSA1 is a TrenchStop™ IGBT transistor from Infineon Technologies with a maximum power of 246W.

  • Manufacturer: Infineon Technologies
  • Technology: TrenchStop™ IGBT
  • Maximum Power: 246W
  • Reverse Recovery Time: 87ns
  • Collector Current (Ic): 67A
  • Maximum Collector Pulsed Current (Icm): 120A
  • Collector-Emitter Breakdown Voltage: 600V
  • Maximum Gate-Emitter Voltage: 15V
  • Switching Energy (On): 1.06mJ
  • Switching Energy (Off): 610μJ
  • Gate Charge: 177nC
  • Package: TO-247-3
  • Mounting: through hole
  • Application: discrete semiconductor products, transistors-IGBTs-single
