Same model may have multiple batches, images only for reference.

CLT-113-02-L-D-P-TR

Name: CLT-113-02-L-D-P-TR
Brand: Samtec Inc.
SKU: 1340040
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	CLT-113-02-L-D-P-TR
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	CONN RCPT 26POS 0.079 GOLD SMD / 26 Position Receptacle Connector 0.079" (2.00mm) Surface Mount Gold
Datasheet	CLT-113-02-L-D-P-TR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects - Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	CLT
Package	Tape & Reel
Connector Type	Receptacle
Contact Type	Female Socket
Style	Board to Board
Number of Positions	26
Number of Positions Loaded	All
Pitch - Mating	0.079" (2.00mm)
Number of Rows	2
Row Spacing - Mating	0.079" (2.00mm)
Mounting Type	Surface Mount
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	10.0µin (0.25µm)
Insulation Color	Black
Insulation Height	0.083" (2.10mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Tin
Features	Pick and Place
Current Rating (Amps)	4.1A per Contact
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Base Product Number	CLT-113
Standard Package	1,225
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
California Prop 65	Warning Information
Win Source Part Number	1340040-CLT-113-02-L-D-P-TR
Ultra Librarian 3D Model	Ultra Librarian CLT-113-02-L-D-P-TR CAD Model

Alternative Products

Description

The CLT-113-02-L-D-P-TR is a rectangular connector used in headers, receptacles, and female sockets from Samtec Inc.

Connector Type: Header, Receptacle, Female Socket
Number of Positions: 26
Features: Pick and Place
Type: Receptacle
Number of Positions Loaded: All
Number of Rows: 2
Termination: Solder
Fastening Type: Push-Pull
Packaging: Tape & Reel (TR)
Contact Material: Phosphor Bronze
Insulation Material: Liquid Crystal Polymer (LCP)
Style: Board to Board
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish - Post: Tin
Operating Temperature: -55°C ~ 125°C
Current Rating (Per Contact): 4.1A
