BC857B Vishay
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single Bipolar Transistors
Mfr Infineon Technologies
Package Bulk
Product Status Obsolete
Transistor Type PNP
Current - Collector (Ic) (Max) 100 mA
Voltage - Collector Emitter Breakdown (Max) 45 V
Vce Saturation (Max) @ Ib, Ic 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 220 @ 2mA, 5V
Power - Max 250 mW
Frequency - Transition 100MHz
Temperature Range - Operating 150°C (TJ)
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23-3
Base Product Number BC857
Standard Package 3,000 pcs
ECCN EAR99
HTSUS 8541.21.0075
Win Source Part Number 74124-BC857B
Package Cut Tape (CT)
Product Status Active
Current - Collector (Ic) (Max) 100mA
Voltage - Collector Emitter Breakdown (Max) 45V
Vce Saturation (Max) @ Ib, Ic 500mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 100nA
Power - Max 200mW
Operating Temperature 150°C (TJ)
Grade -
Supplier Device Package SOT-23
Ultra Librarian 3D Model Ultra Librarian BC857B CAD Model

Description

BC857B

The BC857B is a reliable and efficient PNP transistor widely used in electronic applications requiring precise control and amplification of signals. Its unparalleled performance makes it a staple in the electronic industry.

  • Applications:
    • Amplifiers in audio equipment
    • Signal processing in communication devices
    • Switching in computerized systems
  • Features and Benefits:
    • Good current gain for improved signal integrity
    • Wide operating temperature range ensures reliability
    • Small package for compact electronic designs
  • Additional Details:

    The BC857B's distinct features make it ideal for use in advanced electronic systems, ensuring high efficiency and minimal signal loss.
