MPC9600AER2 Real Image MPC9600AER2 Real Image
Same model may have multiple batches, images only for reference.
MPC9600AER2 Real Image MPC9600AER2 Real Image
MPC9600AER2 Real Image MPC9600AER2 Real Image
Same model may have multiple batches, images only for reference.

MPC9600AER2

Part No MPC9600AER2
Manufacturer IDT, Integrated Device Technology Inc
Catalog HOT - SALES and EOL Components
Description IC PLL CLK DRIVER LV 48-LQFP / Clock Generator 16.67MHz to 50MHz-IN 200MHz-OUT 48-Pin TQFP T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer IDT, Integrated Device Technology Inc
Packaging Tape and Reel
Status Obsolete
Type PLL Clock Driver
PLL Yes with Bypass
Input LVCMOS, LVPECL
Output LVCMOS
Frequency - Max 200MHz
Divider/Multiplier Yes/Yes
Supply Voltage (V) 2.375V ~ 3.465V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 48-LQFP
Supplier Device Package 48-TQFP (7x7)
Family Part Number MPC9600
Manufacturer Pack Quantity 2,000
MSL Level 3 (168 Hours)
Win Source Part Number 059480-MPC9600AER2
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MPC9600
Introduction Date May 28, 2004
ECCN EAR99
Country of Origin Philippines, Taiwan
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian MPC9600AER2 CAD Model

Description

The MPC9600AER2 is a PLL Clock Driver designed for use in a wide range of applications.

  • Manufacturer: IDT, Integrated Device Technology Inc
  • Series: Win Source Series
  • Benefit: high level of performance
  • Ideal For: applications such as networking, telecommunications, and other high-performance applications
  • Supply and Demand Status: balanced
