Same model may have multiple batches, images only for reference.
DF13-6P-1.25V(20) Real Image
Same model may have multiple batches, images only for reference.

DF13-6P-1.25V(20)

Part No DF13-6P-1.25V(20)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 6POS 1.25MM / Connector Header Surface Mount 6 position 0.049" (1.25mm)
Datasheet
DF13-6P-1.25V(20) Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Hirose Electric Co Ltd
Series DF13
Package Tube
Product Status Obsolete
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.049" (1.25mm)
Number of Positions 6
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting SMD (SMT)
Termination Solder
Fastening Type Detent Lock
Insulation Height 0.189" (4.80mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Board Guide, Solder Retention
Temperature Range - Operating -35°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Beige
Current Rating (Amps) 1A
Voltage Rating 150V
Mated Stacking Heights 5.8mm
Base Product Number DF13
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names *DF13-6P-1.25V(20),DF13-6P-1.25V,DF13-6P-1.25V20,DF136P125V20,H2211
Standard Package 39
Win Source Part Number 1221249-DF13-6P-1.25V(20)
Ultra Librarian 3D Model Ultra Librarian DF13-6P-1.25V(20) CAD Model

Description

The Hirose Electric Co Ltd DF13-6P-1.25V(20) is a male pin header connector with a detent lock fastening type.

  • GPTDescription: It has 6 positions loaded and is board to cable/wire style.
  • GPTDescription: The connector has a voltage rating of 150V and a current rating of 1A.
  • GPTDescription: It has a pitch-mating of 0.049 inches (1.25mm) and the contact finish-mating and post is tin.
  • GPTDescription: It is supplied in a tube package and is SMD (SMT) mountable.
