Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr GOOD-ARK Electronics
Package Tube
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology Standard
Voltage - DC Reverse (Vr) (Max) 400 V
Current - Average Rectified (Io) (per Diode) 20A
Voltage - Forward (Vf) (Max) @ If 1.5 V @ 20 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 35 ns
Current - Reverse Leakage @ Vr 10 µA @ 400 V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220-3
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 832217-MUR2040CT
Ultra Librarian 3D Model Ultra Librarian MUR2040CT CAD Model

Description

The MUR2040CT is a fast recovery diode array designed for rectification of AC line voltage.

  • Maximum DC Reverse Voltage: 400V
  • Forward Voltage: 1.5V @ 20A
  • Diode Configuration: 1 pair of common cathode diodes
  • Reverse Recovery Time: 35ns
  • Current Leakage: 10μA @ 400V
  • Operating Temperature: -55°C to 150°C
  • Package: TO-220-3
  • Mounting: Through-hole
  • Standard Package: 50 pieces
  • Manufacturer: GOOD-ARK Electronics
  • Status: Active
