MUR5020 America Semiconductor, LLC
Same model may have multiple batches, images only for reference.

MUR5020

Part No MUR5020
Manufacturer GeneSiC Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 200V 50A DO5
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr GeneSiC Semiconductor
Package Bulk
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) 50A
Voltage - Forward (Vf) (Max) @ If 1 V @ 50 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 75 ns
Current - Reverse Leakage @ Vr 10 µA @ 50 V
Mounting Type Chassis, Stud Mount
Package / Case DO-203AB, DO-5, Stud
Supplier Device Package DO-5
Operating Temperature - Junction -55°C ~ 150°C
Standard Package 100 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 645885-MUR5020
Ultra Librarian 3D Model Ultra Librarian MUR5020 CAD Model

Description

The MUR5020 is a fast recovery rectifier diode designed for high-speed applications.

  • Voltage Rating: 200V
  • Average Rectified Current: 50A
  • Suitable for: various power rectification tasks
  • Forward Voltage Drop: 1V @ 50A
  • Reverse Recovery Time: 75 ns
  • Operating Temperature: -55°C to 150°C
  • Package: DO-203AB
  • Mounting: stud mount
  • Manufacturer: GeneSiC Semiconductor
  • Reliable choice for: rectification applications that require high-speed performance and durability
