GBU15K GeneSiC Semiconductor
Same model may have multiple batches, images only for reference.

GBU15K

Part No GBU15K
Manufacturer GeneSiC Semiconductor
Catalog Bridge Rectifiers
Description SILICON BRIDGE RECTIFIERS | BRIDGE RECT 1PHASE 800V 15A GBU
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 800V
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Maximum) at If 1.1V at 15A
Current - Reverse Leakage at Vr 5μA at 800V
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package 4-SIP, GBU
Supplier Device Package GBU
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Win Source Part Number 1177017-GBU15K
Manufacturer Homepage www.galaxycn.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GBU15K CAD Model

Description

The GBU15K is a single-phase diode from GeneSiC Semiconductor.

  • Maximum Peak Reverse Voltage: 800V
  • Average Rectified Current: 15A
  • Operating Temperature Range: -55°C to 150°C
  • Package: 4-SIP, GBU
  • Forward Voltage: 1.1V @ 15A
