Applications:

• RF Circuits: Used in RF filters, matching networks, and tuning circuits.
• Wireless Communication Devices: Found in smartphones, tablets, and other wireless devices.
• Power Supplies: Utilized in DC-DC converters and power management circuits.
• Medical Devices: Employed in medical equipment for signal filtering and impedance matching.
• Automotive Electronics: Used in automotive applications for noise filtering and signal conditioning.

Features:

• Wire-Wound Construction: Offers high Q factor and good current handling capability.
• Surface Mount Package: Designed for automated assembly on printed circuit boards.
• Compact Size: Saves space in densely populated circuits.
• High SRF (Self-Resonant Frequency): Ensures stable performance at high frequencies.
• RoHS Compliant: Manufactured in compliance with RoHS standards, minimizing environmental impact.

Benefits:

• Improved Circuit Performance: Enhances circuit performance by minimizing losses and improving signal quality.
• Efficient Power Management: Enables efficient power conversion and regulation.
• Compact Design: Allows for smaller and more compact circuit designs.
• Reliable Operation: Provides stable and reliable performance in demanding environments.
• Simplified Assembly: Simplifies the assembly process with its surface mount design.

Technical Specifications:

Key specifications for the 1008C-1R2J inductor include:

• Inductance: 1.2µH (indicated by 1R2, where R represents the decimal point).
• Tolerance: Typically ±5% or ±10% (indicated by J)
• Package Size: 1008 (100 x 80 mils, or approximately 2.5mm x 2.0mm)
• Self-Resonant Frequency (SRF): Varies depending on the specific part, but is typically in the MHz range.
• DC Resistance (DCR): Low DCR for minimal power loss.
• Rated Current: The maximum current the inductor can handle without significant performance degradation.
• Q Factor: High Q factor at specific test frequencies.

Refer to the Frontier Electronics datasheet for the most accurate and detailed specifications.
