MPX5500DP Freescale Semiconductor - NXP MPX5500DP Real Image MPX5500DP real image MPX5500DP real image3642
Same model may have multiple batches, images only for reference.
MPX5500DP Freescale Semiconductor - NXP MPX5500DP Real Image MPX5500DP real image MPX5500DP real image3642
MPX5500DP Freescale Semiconductor - NXP MPX5500DP Real Image MPX5500DP real image MPX5500DP real image3642
Same model may have multiple batches, images only for reference.

MPX5500DP

Part No MPX5500DP
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description Pressure Sensor 0.2V to 4.7V 0kPa to 500kPa Differential 6-Pin Case 867C-05 Tray / IC SENSOR PRESS GAUGE 75PSI RANG
Datasheet
MPX5500DP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Differential
Operating Pressure 72.52 PSI (500 kPa)
Output Type Analog Voltage
Output 0.2 V to 4.7 V
Accuracy ±2.5%
Supply Voltage - Operating 4.75 V to 5.25 V
Port Size Male - 0.19" (4.93mm) Tube, Dual
Port Style Barbed
Features Temperature Compensated
Termination Style PCB
Maximum Pressure 406.11 PSI (2800 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 086002-MPX5500DP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals
Family Name MPX5500
Introduction Date December 16, 1994
ECCN EAR99
Country of Origin Republic of Korea, United States of America
Halogen Free Not Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian MPX5500DP CAD Model

Description

The NXP 086002-MPX5500DP is a differential pressure sensor with a male 0.19" (4.93mm) tube, dual port style.

  • Output: temperature-compensated analog voltage output of 0.2 V to 4.7 V with an accuracy of ±2.5%
  • Operating Temperature Range: -40°C to 125°C
  • Maximum Operating Pressure: 406.11 PSI (2800 kPa)
  • Commonly Used In: computers and computer peripherals
  • Popularity: high
  • Estimated EOL Date: 2025
