Same model may have multiple batches, images only for reference.
MPX53GP Real Image
Same model may have multiple batches, images only for reference.

MPX53GP

Part No MPX53GP
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description SENSOR GAUGE PRESSURE 7 PSI MAX
Datasheet
MPX53GP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Vented Gauge
Operating Pressure 7.25 PSI (50 kPa)
Output Type Wheatstone Bridge
Output 0 mV to 60 mV (3V)
Accuracy -0.6% to 0.4%
Supply Voltage - Operating 3 V to 6 V
Port Size Male - 0.19" (4.93mm) Tube
Port Style Barbed
Termination Style PCB
Maximum Pressure 25.38 PSI (175 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 208784-MPX53GP
Ultra Librarian 3D Model Ultra Librarian MPX53GP CAD Model

Description

The NXP MPX53GP is a vented gauge pressure sensor for use in electronic applications.

  • Operating Pressure: 7.25 PSI (50 kPa)
  • Maximum Pressure: 25.38 PSI (175 kPa)
  • Termination Style: PCB
  • Output Type: Wheatstone Bridge
  • Accuracy: -0.6% to 0.4%
  • Output: 0 mV to 60 mV @ 3V
  • Port Size: male - 0.19" (4.93mm) Tube
  • Port Style: barbed
  • Operating Temperature Range: -40°C to 125°C
  • Supply Voltage: 3 V to 6 V
