MPX2100GP Real Image
Same model may have multiple batches, images only for reference.

MPX2100GP

Part No MPX2100GP
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description SENSOR GAUGE PRESS 14.5 PSI MAX
Datasheet
MPX2100GP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Obsolete(EOL)
Pressure Type Vented Gauge
Operating Pressure 14.5 PSI (100 kPa)
Output Type Wheatstone Bridge
Output 0 mV to 40 mV (10V)
Supply Voltage - Operating 10 V to 16 V
Port Size Male - 0.19" (4.93mm) Tube
Port Style Barbed
Features Temperature Compensated
Termination Style PCB
Maximum Pressure 58.02 PSI (400 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 208782-MPX2100GP
Ultra Librarian 3D Model Ultra Librarian MPX2100GP CAD Model

Description

The NXP MPX2100GP is a pressure sensor with a vented gauge pressure type and a maximum operating pressure of 58.02 PSI (400 kPa).

  • Port Size: male 0.19-inch (4.93mm) tube
  • Port Style: barbed
  • Feature: temperature-compensated
  • Output Type: Wheatstone bridge
  • Output: 0 mV to 40 mV (10V)
  • Accuracy: not specified
  • Supply Voltage: 10 V to 16 V
  • Termination Style: PCB
  • Status: obsolete (EOL)
