MMSZ5243B Fairchild/ON Semiconductor MMSZ5243B Real Image1 MMSZ5243B Real Image2
Same model may have multiple batches, images only for reference.
MMSZ5243B Fairchild/ON Semiconductor MMSZ5243B Real Image1 MMSZ5243B Real Image2
MMSZ5243B Fairchild/ON Semiconductor MMSZ5243B Real Image1 MMSZ5243B Real Image2
Same model may have multiple batches, images only for reference.

MMSZ5243B

Part No MMSZ5243B
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes - Zener - Single
Description DIODE ZENER 13V 500MW SOD123
Datasheet
MMSZ5243B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Voltage - Zener (Nom) (Vz) 13V
Tolerance ±5%
Maximum Power Dissipation 500mW
Impedance (Max) (Zzt) 13 Ohm
Current - Reverse Leakage @ Vr 500nA @ 9.9V
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Temperature Range - Operating -55°C to 150°C
Mounting SMD (SMT)
Case / Package SOD-123
Win Source Part Number 084290-MMSZ5243B
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian MMSZ5243B CAD Model

Description

Its supply and demand status is sufficient.

  • Voltage-Forward (Vf): 900mV @ 10mA
  • Current-Reverse Leakage @ Vr: 500nA @ 9.9V
  • Voltage-Zener (Nom) (Vz): 13V
  • Impedance (Max) (Zzt): 13 Ohm
  • Case / Package: SOD-123
  • Maximum Power Dissipation: 500mW
