MMBD1503A Fairchild/ON Semiconductor MMBD1503A Real Image MMBD1503A real image 2 MMBD1503A label picture
Same model may have multiple batches, images only for reference.
MMBD1503A Fairchild/ON Semiconductor MMBD1503A Real Image MMBD1503A real image 2 MMBD1503A label picture
MMBD1503A Fairchild/ON Semiconductor MMBD1503A Real Image MMBD1503A real image 2 MMBD1503A label picture
Same model may have multiple batches, images only for reference.

MMBD1503A

Part No MMBD1503A
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Arrays
Description Rectifier Diode Small Signal Switching 200V 0.2A 3-Pin SOT-23 T/R / DIODE ARRAY GP 200V 200MA SOT23
Datasheet
MMBD1503A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Series Connection
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 200V
Current - Average Rectified (Io) (per Diode) 200mA
Voltage - Forward (Vf) (Max) @ If 1.1V @ 200mA
Current - Reverse Leakage @ Vr 10nA @ 180V
Operating Temperature - Junction 150°C (Max)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 023650-MMBD1503A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Automation & Process Control, Signal Processing
Quantity per package 3k pcs
Family Name MMBD1503A
Introduction Date May 03, 1998
ECCN EAR99
Country of Origin China, Philippines, Republic of Korea, Thailand
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian MMBD1503A CAD Model

Description

The MMBD1503A is a standard diode type manufactured by Fairchild/ON Semiconductor.

  • Mounting: SMD (SMT) package
  • Voltage DC Reverse: 200V
  • Voltage Forward: 1.1V @ 200mA
  • Current Reverse Leakage: 10nA @ 180V
  • Junction Temperature: 150°C (Max)
  • Current Average Rectified: 200mA
  • Applications: Industrial, automation & process control, and signal processing
  • Supply and Demand Status: Limited
  • Package Contains: 3,000 pieces
