MBR3045PT Real Image
Same model may have multiple batches, images only for reference.

MBR3045PT

Part No MBR3045PT
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Arrays
Description Schottky Rectifiers | DIODE ARRAY SCHOTTKY 45V TO3P
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube
Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 45V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Maximum) at If 760mV at 30A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 1mA at 45V
Operating Temperature - Junction -65°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package TO-3P-3, SC-65-3
Supplier Device Package TO-3P
Family Part Number MBR3045PT
Manufacturer Pack Quantity 30
MSL Level 1 (Unlimited)
Win Source Part Number 1216100-MBR3045PT
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MBR3045PT CAD Model

Description

The Fairchild/ON Semiconductor 503050 is a fast recovery Schottky diode pair with a common cathode configuration.

  • Maximum DC reverse voltage: 45V
  • Current rating: 30A
  • Applications: power management
  • Packages: TO-3P-3 and SC-65-3
  • Mounting: through hole
  • Operating temperature: -65°C to 150°C
  • Status: obsolete
  • Supply and demand status: limited
  • Alternative parts: MBR3045PTG, STPS3045CPI, and SD241P/45
