HGTG10N120BND

Name: HGTG10N120BND
Brand: Fairchild/ON Semiconductor
SKU: 597666
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	HGTG10N120BND
Manufacturer	Fairchild/ON Semiconductor
Catalog	IGBTs - Single
Description	35A, 1200V, NPT Series N-Channel IGBT with Anti-Parallel Hyperfast Diode
Datasheet	HGTG10N120BND Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Tube
IGBT Type	NPT
Voltage - Collector Emitter Breakdown (Maximum)	1200V
Current - Collector (Ic) (Maximum)	35A
Current - Collector Pulsed (Icm)	80A
Vce(on) (Maximum) @ Vge, Ic	2.7V @ 15V, 10A
Power - Max	298W
Switching Energy	850μJ (on), 800μJ (off)
Input Type	Standard
Gate Charge	100nC
Td (on/off) @ 25°C	23ns/165ns
Test Condition	960V, 10A, 10 Ohm, 15V
Reverse Recovery Time (trr)	70ns
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting Style	Through Hole
Package	TO-247-3
Manufacturer Package	TO-247
Win Source Part Number	1180354-HGTG10N120BND
Manufacturer Homepage	www.fairchildsemi.com
Family Name	HGTG10N120B
Introduction Date	December 17, 2001
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2019
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	450
Ultra Librarian 3D Model	Ultra Librarian HGTG10N120BND CAD Model

Alternative Products

Description

The HGTG10N120BND is an NPT IGBT with a maximum power of 298W, manufactured by Fairchild/ON Semiconductor.

Voltage Breakdown: 1200V
Maximum Collector Current: 35A
Popularity: Medium
Supply and Demand Status: Balanced
Temperature Range: -55°C to 150°C
Switching Energy (on): 850μJ
Switching Energy (off): 800μJ
